DS-215SS Platform Scale

Get a Price/Quote

Product Details:

IP Rating IP65
Features Piece Counting, Tare Function, Overload Protection, Zero Tracking
Battery Life Up to 8 hours (with inbuilt rechargeable battery)
Application Warehouse, Factories, Transportation, Shops
Size 600 x 600 mm platform
Usage Industrial
Display Type Digital LED
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DS-215SS Platform Scale Price And Quantity

DS-215SS Platform Scale Product Specifications

Weighing Scale Type Digital
Product Type Platform Scale
Function Weighing
Material Stainless Steel
Application Warehouse, Factories, Transportation, Shops
Battery Life Up to 8 hours (with inbuilt rechargeable battery)
Connectivity Type Wired
Load Up to 1000 kg
Capacity Range 50 kg to 1000 kg
Interface RS232
Features Piece Counting, Tare Function, Overload Protection, Zero Tracking
Monitor Display LED Display
Automatic Grade Automatic
Usage Industrial
Size 600 x 600 mm platform
Power Supply 230V AC, 50 Hz
Power Source Electric
Display Type Digital LED
Color Silver
IP Rating IP65
Accuracy 10 g - 50 g

Product Description

Equipped with mild steel, offered DS 215SS Platform Scale is driven by 6V 4 AH battery. This weight measurement scale has total 5 keys. Display screen of this product has 0.56 inch dimension and it has red backlight arrangement. This screen can show measured value in 6 digits. Provided DS 215SS Platform Scale requires 230v AC power to operate and its frequency is 50 Hz. Design of this product is approved by CE. Approximate scale size of this product is 325 x 285 x 500. This high performance platform scale has overload protection arrangement. It adopts advanced load cell technology.

Technical Specification

Power supply	230V AC, 50 Hz
Display colour/digit	RED / 6 Digits
Display size	0.56" (14.22 mm)
Number of keys	5 Keys
Battery	6V / 4AH
Frame MOC	MS(for all the types)

Robust Construction for Challenging Environments

Engineered with stainless steel and an anti-rust platform, the DS-215SS is tailored for industrial use. Its IP65 protection ensures resistance to dust and low-pressure water, making it apt for demanding warehouse and factory settings. The scales adjustable, non-slip feet provide both stability and adaptability on uneven surfaces.

High Precision and Swift Response

Experience accurate measurements with a capacity ranging from 50 kg up to 1000 kg and fine accuracy levels between 10 g and 50 g. The scale features a rapid response time of three seconds or less, ensuring prompt and reliable results for every weigh-in, essential for high-traffic, fast-paced environments.

User-Friendly Operation and Versatile Features

The DS-215SS offers intuitive operation with a bright LED display and functions such as piece counting, tare, and zero tracking. Its RS232 connectivity enables seamless integration with industrial systems. Choose between wired power (230V AC) or switch to the inbuilt rechargeable battery for up to eight hours of cordless use.

FAQs of DS-215SS Platform Scale:

Q: How do I calibrate the DS-215SS platform scale for accurate measurements?

A: Calibration of the DS-215SS platform scale is typically performed by following the procedures outlined in the user manual, using certified calibration weights within the specified range of 50 kg to 1000 kg. Regular calibration ensures continued precision, especially in industrial or high-usage environments.

Q: What types of locations are suitable for using this platform scale?

A: The DS-215SS is suitable for industrial locations such as warehouses, factories, transportation centers, and retail shops. Its IP65 rating, stainless steel construction, and anti-rust platform make it ideal for settings that require both robustness and cleanliness.

Q: When should I use the tare and piece counting functions on the scale?

A: Use the tare function when you need to exclude the weight of containers, allowing for precise net weight readings. The piece counting feature is helpful when you need to count multiple identical items based on their individual unit weight, streamlining inventory processes.

Q: Where can I view the weight measurement, and in what units are the results displayed?

A: Weight measurements are displayed on the digital LED screen for clear visibility. The scale provides readings in kilograms (kg) and grams (g), catering to diverse weighing requirements.

Q: What is the benefit of the scales short circuit and overvoltage protection?

A: Short circuit and overvoltage protection safeguard the internal electronics of the DS-215SS against electrical irregularities, ensuring reliable operation and prolonging the products lifespan in environments with variable power supply.

Q: How is the DS-215SS powered, and what is its battery life?

A: The DS-215SS operates on a 230V AC, 50 Hz power supply for continuous use. Additionally, it features an inbuilt rechargeable battery providing up to 8 hours of operation, making it flexible for usage during power interruptions or in mobile setups.

Q: What process should be followed to connect the scale to external systems?

A: To integrate the DS-215SS with external systems, utilize the RS232 wired interface, following the manufacturers connection guidelines. This enables data transfer to computers or printers for record-keeping or further processing.
