Moisture Analyser Weighing Balance

Moisture Analyser Weighing Balance

Product Details:

X

Product Description

Technical Specification

Measurement Method

400 W straight halogen lamp heating system with SRA filter and SHS weighing technology

Max Sample Weight Capacity

51 g

Weight Resolution

0.001 g

Moisture Content Display

0.01% / 0.1%

Moisture Content Accuracy over 1g

0.10%

(Standard Deviation) over 5g

0.02%

Heating Technology

Halogen lamp (Straight type, 400 Watt max, 5000 hours)

Drying Temperature (1°C increment)

50-200°C

Memory of Measurement Programs

20 sets

Measurement Programs

Standard Mode/Automatic Mode/Quick Mode/Timer Mode/Manual Mode

Measurement Mode

Moisture content(Wet or Dry base) /Dry content/Ratio/Weight

Heating Mode

Standard / Quick / Step /Ramp

Display Type

Large VFD

Interface

RS-232C standard

Data Memory Function

100

Operating Temperature

5-40°C (41-104°F) less than 85%RH

GLP/GMP/ISO

Available

Self Check Function

Standard

Communication Software

WinCT-Moisture standard

Sample Pan Size

Ø85 mm

Power

AC 200V to 240V (1.5A), 50/Hz, Approx. 400W

Physical Dimention/Weight

215(W) x 320(D) x 173(H) / Approx. 6 kg

Standard Accessories

Sample Pans - 20, Pan Handles -2, Spoon, Test Sample (30g of Sodium Tartrate Dihydrate), CD-ROM (WinCT-Moisture), Glass Fiber Sheet, RS-232C Cable, Display Cover, Dust Cover, Instruction Manual, Quick Reference Card, Power Cable, Fuse
