SI-810 Volumetric Scale

Get a Price/Quote

Product Details:

Usage Industry, Courier, Cargo, Postal Services
Power Source Electric
Interface USB, RS232
Application Logistics, Ecommerce, Warehousing, Cargo Management
Connectivity Type Wired
Features Heavy Duty Platform, Easy-to-use, Fast and Accurate Measurement, User-friendly Interface, Data Output Capability
Function Measuring both Volumetric & Actual Weight
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

SI-810 Volumetric Scale Price And Quantity

SI-810 Volumetric Scale Product Specifications

Weighing Scale Type Digital Volumetric Weighing Scale
Capacity Range Up to 50 kg (weight), Volume: 500mm x 500mm x 500mm
Monitor Display LCD Display
Product Type Volumetric Scale
Display Type Digital LCD
IP Rating IP54
Load Up to 50 kg
Accuracy High Precision, up to 10g
Size Platform: 600mm x 600mm
Power Supply 230V AC, 50Hz
Application Logistics, Ecommerce, Warehousing, Cargo Management
Connectivity Type Wired
Interface USB, RS232
Power Source Electric
Automatic Grade Semi-Automatic
Color Blue & Grey
Function Measuring both Volumetric & Actual Weight
Material Mild Steel (MS)
Usage Industry, Courier, Cargo, Postal Services
Features Heavy Duty Platform, Easy-to-use, Fast and Accurate Measurement, User-friendly Interface, Data Output Capability

Product Description

SI-810 Volumetric Scale deserves praise for its ergonomic look and optimum structural strength. This scale is equipped with 600 x 600 mm platform and red light based class 2 sensor. Its measurement time and increment is 4 second (maximum) and 5 mm respectively. This machine adopts mm and cm based units. Its maximum weight is 50 kg. This SI-810 Volumetric Scale is capable of handling objects having maximum 530 mm long, 530 mm wide and 530 mm high objects. Maximum length, width and height of objects that it can deal is 30 mm. Long working life and error free mechanism are its main aspects.

Technical Specification

Weighing unit	kg
Measuring unit	cm, mm
Maximum weight	50 kg
Weighing increment	5 g
Platform size	600 x 600 mm
Measuring sensor	Red Light Sensor class 2

Performance Specifications

Maximum object size	530 mm [Length] 530 mm [Width] 530 mm [Height]
Minimum object size	30 mm [Length] 30 mm [Width] 30 mm [Height]
Measuring increment	5 mm
Measurement time	3-4s

Other Specifications

Object shape	Rectangular solid objects. Other shapes may vary from quoted specification
System interface	USB - HID, Ethernet [TCP/IP] RJ45
Power requirement	230V AC, 50Hz
Power consumption	30W

Advanced Measurement Technology

The SI-810 Volumetric Scale utilizes ultrasonic sensors to deliver swift and accurate dimension measurement, crucial for logistics, warehousing, and e-commerce operations. Its ability to calculate both volumetric and actual weight helps optimize shipping charges and inventory management, making it a reliable tool for businesses with high parcel turnover.

User-Friendly and Versatile Operation

Designed for ease of use, the SI-810 features a large, anti-slip stainless steel platform, clear LCD display, and intuitive controls. Compatible with Windows systems, it offers selectable data output formats and supports simultaneous USB and RS232 communication, ensuring seamless integration within various IT environments.

Durability and Compliance

Built with mild steel and an IP54-rated enclosure, the SI-810 resists dust and water ingress, making it suitable for demanding industrial settings. Its legal-for-trade approval ensures regulatory compliance, while internal/external calibration options maintain high accuracy over time.

FAQs of SI-810 Volumetric Scale:

Q: How does the SI-810 Volumetric Scale measure dimensions?

A: The SI-810 uses an ultrasonic sensor to measure package dimensions, accurately calculating the volume up to 125 liters within a 500mm x 500mm x 500mm space. This non-contact method ensures quick and precise readings suitable for various industrial and logistics applications.

Q: What data output formats and connectivity options are available with the SI-810?

A: Data can be exported in selectable formats such as CSV or TXT. The scale features simultaneous dual-port connectivity via USB and RS232, allowing for flexible data integration with Windows PCs and other management systems.

Q: When should I calibrate the SI-810 and how is it performed?

A: Calibration should be performed periodically, especially after relocation or significant temperature changes. The SI-810 supports both internal and external calibration, ensuring sustained measurement accuracy in diverse working conditions.

Q: Where is the SI-810 best installed for optimum operation?

A: The SI-810 is a floor-standing device, best placed on a stable and level surface in warehouses, logistic hubs, courier stations, or sorting areas where parcels and cargo are regularly measured and weighed.

Q: What are the benefits of using the SI-810 Volumetric Scale?

A: The SI-810 offers fast and accurate volumetric and actual weight measurements, optimizing shipping costs and logistics processes. Its durable build, legal-for-trade compliance, and user-friendly interface enhance efficiency and reliability for industrial users.

Q: Which applications and industries is the SI-810 suitable for?

A: Ideal for logistics, e-commerce, courier, cargo, postal services, and warehousing, the SI-810 serves exporters, manufacturers, and suppliers who require precise volumetric and weight data for efficient cargo management.
